InteliGen NT BaseBox GeCon
InteliGen NT BaseBox GeCon
Comprehensive gen-set controller for both single and multiple gensets operating in standby or paralleling modes to be used in conjunction with detachable colour displays InteliVision 5 or InteliVision 8. Support of engines with ECU (Electronic Control Unit)
Complete integrated gen-set solution and signal sharing via CAN bus – minimum external
components needed
Many communication options – easy remote supervising and servicing
Load sharing and VAr sharing via CANVirtual shared inputs and outputs via CAN Support of wide range of applications
Single or multiple gen-sets in parallel to mains operation with automatic back up function,
multiple island operation
Advanced power management function Customizable load control in parallel to mains Wide range of ECU support
Highly configurable
Timers, Internal PLC, Force values and more compatible with ComAp's InteliVision displays Active e-mail messaging and SMSExtensive built-in protection functions
Standard protections. User configurable protection.
» IG-NT-BB-Datasheet
Comprehensive gen-set controller for both single and multiple gensets operating in standby or paralleling modes to be used in conjunction with detachable colour displays InteliVision 5 or InteliVision 8. Support of engines with ECU (Electronic Control Unit)
Complete integrated gen-set solution and signal sharing via CAN bus – minimum external
components needed
Many communication options – easy remote supervising and servicing
Load sharing and VAr sharing via CANVirtual shared inputs and outputs via CAN Support of wide range of applications
Single or multiple gen-sets in parallel to mains operation with automatic back up function,
multiple island operation
Advanced power management function Customizable load control in parallel to mains Wide range of ECU support
Highly configurable
Timers, Internal PLC, Force values and more compatible with ComAp's InteliVision displays Active e-mail messaging and SMSExtensive built-in protection functions
Standard protections. User configurable protection.
| Technical Data | |
| Power Supply Range | 8 – 36 VDC |
| Operating temperature | -40°C to 70°C |
| Number of binary inputs | 12 non-isolated |
| Number of binary outputs | 12 non-isolated |
| Number of analog inputs | 3 non-isolated |
| Magnetic pick-up Voltage input range |
2 Vpk-pk to 50 Veff |
| Current Measurement Inputs | 3 ph Gen current 1 ph Mains current galvanically isolated |
| Voltage Measurement Inputs | 3 ph-n Gen voltage 3 ph-n Mains/Bus voltage |
| Voltage regulator output Type | 5 V TTL PWM / ± 10 VDC with IG-AVRi interface |
| Speed governor Voltage output | ± 10 VDC / max.10 mA |
